Proizvodi - industrijska, telekom i vojna napajanja

Walter - Industrijski DC/AC sinusni invertori

DC/AC Inverters - High Efficiency Sinewave Solution



Uporedne tabele



Karakteristika CETUS1500-220 CORONA3000-220
Output power 1500 VA 3000 VA
Input voltage 24-110 V 24-110 V
Output voltage 230 Vac 230 Vac
Frequency 50Hz ± 0.1% 50Hz ± 0.1%
Output voltage waveform sinus sinus
Output volt.THD <2% <2%
Input current ripple <10% Inom <10% Inom
Efficiency >90% >90%
Static stability <0.5% <0.5%
Dyn. stability <5% / 0.1ms <5% / 0.1ms
Insulation - I/C 2.1kV 2.1kV
Insulation - O/ C 2.1kV 2.1kV
Insulation - I/O 4kV 4kV
Dimensions 19’’, 2H, 300mm 19’’, 2H, 300mm
Operating temperature 0-55ºC 0-55ºC
Cooling Fan Fan
Processor control Yes Yes
Diagnostic display Option Option
Parallel operation Yes Yes
Order code U1I152A48-220-CTS U1I302A110-220-CRN
