On-Line UPS. Neprekidna napajanja
Uporedne tabele
| Karakteristika | LAMBDA1000 | LAMBDA2000 | LAMBDA3000 |
|---|---|---|---|
| Output power | 1000 VA | 2000 VA | 3000 VA |
| Input voltage | 160-275 V | 160-275 V | 160-275 V |
| Output voltage | 230Vac, 63Vac | 230Vac, 63Vac | 230Vac, 63Vac |
| Output voltage waveform | sinus | sinus | sinus |
| Output volt.THD | <2% | <2% | <2% |
| Configuration | on line, double conversion | on line, double conversion | on line, double conversion |
| Transfer time | 0s | 0s | 0s |
| Autonomy | 6min .. 12h | 6min .. 12h | 6min .. 12h |
| Battery recovery time | 4h | 4h | 4h |
| Overload protection | 120% load -> 5min, 150% load -> 10min | 120% load -> 5min, 150% load -> 10min | 120% load -> 5min, 150% load -> 10min |
| Dimensions | 320x165x390mm | 320x165x390mm | 320x165x390mm |
| Diagnostic | LCD 2x16char. | LCD 2x16char. | LCD 2x16char. |
| LED indicators | 4 LEDs+LEDbar | 4 LEDs+LEDbar | 4 LEDs+LEDbar |
| Command | 4 buttons | 4 buttons | 4 buttons |
| Autorestart | yes | yes | yes |
| Communication | USB serial | USB serial | USB serial |
| Operating temperature | 0-55ºC | 0-55ºC | 0-55ºC |
| Processor control | yes | yes | yes |
| Order code | U1W102A220-220-LMD U1W102A220-63-LMD | U1W202A220-220-LMD U1W202A220-63-LMD | U1W302A220-220-LMD U1W302A220-63-LMD |
UPS versions for CATV application are equipped with 230/63V galvanic insulation transformer with additional EMI filter.
Microprocessor controlled battery charging and UPS monitoring, with temperature compensation.
Providing power directly from the internal batteries (black start function).
Handles power problems: power spikes and transients, EMI/RFI noise, voltage sags and brownout conditions, harmonics, power-factor corrected loads, outages.
